6000lbs 12V Electric Winch 24V DC ATV Winch Self Recovery
Product Details
| Product Name | Car Electric Winch, Truck Electric Winch, Auto Electric Winch | Moror | Pure Motor |
|---|---|---|---|
| Power | Dc Powered Winch | Control | Wire Control Or Wireless Remote Control |
| Color | Black, Red, Blue | After Sales Service | 1 Year |
| Highlight | 6000lbs 12V Electric Winch,24V DC ATV Winch,ATV Winch Self Recovery |
||
Product Description
12/24V Electric Steel Wire Rope Winch 6000 Lbs with Remote Control for Boat Use
Description: Auto electric winch, car electric winch
Electric winch operates on a 12V DC 24V DC system, making it ideal for ATVs, UTVs, and boat trailers, serving as devices for self-recovery and towing. Capacity is 2000lbs, 3000lbs, 3500lbs,4000lbs, 6000lbs, 9000lbs, 12000lbs, 20000lbs.
They enable vehicles to extricate themselves in harsh environments—such as snow, swamps, deserts, beaches, and muddy mountain roads—and facilitate tasks like obstacle removal, object hauling, and equipment installation under various conditions. These winches are indispensable safety devices for sectors including the petroleum, hydrology, environmental protection, forestry, transportation, public security, border defense, and firefighting, as well as for outdoor recreational activities.
Features:
| 1 | Pure copper motor |
| 2 | Wire rope and synthenic rope both offer |
| 3 | Forged hooks |
| 4 | 12V DC, 24DC |
| 5 | Turck electric winch, car electric winch |
| 6 | Easy install and operate |
Technical data
| Electric winch 12V/24V, wire rope length can make according customer's request | ||||||||||
| Model | Rated traction (kg) |
Vertical lifting (kg) |
Motor no-load power (kw) |
Wire rope (diaxlength) |
Size (LxWxH) mm |
Installation dimensions (hole spacing-hole diameter) mm |
Drum dimensions (diameter length) mm |
G.w (kg) |
Wooden case size (LxWxH) cm |
Remart |
| 2000lbs | 900 | 200 | 0.4 | 4mmx6m | 268x110x105 | 76-8.5 | 3.15x72 | 5.80 | 33x24x15 | Without mounting plate and rope guide |
| 3000lbs | 1300 | 300 | 0.55 | 5mmx6m | 299x110x105 | 76-8.5 | 31.5x72 | 6.15 | 33x24x15 | Without mounting plate and rope guide |
| 3500lbs | 1500 | 350 | 0.6 | 5mmx10m | 320x110x105 | 76-8.5 | 31.5x72 | 8.15 | 40x31x16 | With mounting plate and rope guide |
| 4000lbs | 1800 | 400 | 0.8 | 5mmx10m | 343x110x112 | 76-8.5 | 49.5x72 | 9.20 | 40x31x16 | With mounting plate and rope guide |
| 4500lbs | 2000 | 450 | 0.9 | 5mmx10m | 363x110x112 | 76-8.5 | 49.5x72 | 9.55 | 40x31x16 | With mounting plate and rope guide,with remote wireless control |
| 6000lbs | 2700 | 500 | 1.5 | 7mmx14m | 340x160x217 | 165x114-11 | 63x135 | 23.80 | 55x25x32 | Without mounting plate and rope guide |
| 9500lbs | 4300 | 600 | 1.9 | 9mmx24m | 529x160x217 | 255x114-11 | 63x220 | 36.15 | 58x32x29.5 | With rope guid and remoe wireless control, without mounting plate |
| 12000lbs | 5400 | 750 | 2.0 | 9mmx24m | 529x160x217 | 255x114-11 | 63x220 | 37.25 | 58x32x29.5 | With rope guide and remote wireless control, without mounting plate |
| 13000-13500lbs | 6000 | 800 | 2.2 | 9mmx24m | 529x160x217 | 255x114-11 | 63x220 | 37.25 | 58x32x29.5 | With rope guide and remote wireless control, without mounting plate |
| 20000lbs | 9000 | 1000 | 2.8 | 1lmmx24m | 560x196x260 | 255x114-12 | 88x215 | 52.00 | 63x31x23 | With rope guide and remote wireless control, without mounting plate |
Workshop:
FAQ:
1. Are you manufacturer or trading company?
We are manufacturer with our own factories.
2.What’s the warranty for products?
Usually for 1 year for major part, for example, motor, pump. We also offer online service supports.
3.What’s your MOQ?
Negotiate based on the circumstances. EXW term: 1pcs.
4. What’s your payment term?
100% TT under amount 5000USD, 30%TT as down payment, balance before loading when amount more than 5000USD.
5. What about deliver leading time?
About 15 working days
6. Where’s your factory?
Our factory located in Donglv industrial Area, belongs to Baoding city, near Capital Beijing. Convenient transportation. Our nearest port is Tianjin port.
