Customized HHBB Electric Chain Hoist Heavy Duty Chain Hoist With Trolley
Product Details
| Product Name | HHBB Electric Chain Hoist | Mount Type | Hook Type / Trolley Type Optional |
|---|---|---|---|
| Lifting Chain | G80 Alloy Steel Lifting Chain | Lifting Speed | Single Speed / Double Speed Optional |
| Lifting Capacity | 0.5T-50T | Lifting Height | 4m–30m, Customized |
| Power Supply | 220V/380V/415V/440V/50HZ/60HZ/3PH/1PH | Color | Orange, Yellow, Black, Blue, Red,Customized |
| Highlight | customized hhbb electric chain hoist,heavy duty chain hoist with trolley,hhbb electric chain hoist heavy duty |
||
Product Description
HHBB Electric Chain Hoist, Industrial Electric Chain Block, Heavy Duty Lifting Hoist for Workshop Crane
Product Description:
HHBB electric chain hoist is a classic industrial lifting device equipped with Grade G80 high-strength lifting chain. Compact body design ensures stable hoisting. Built-in power-off brake, overload protection and limit switches provide comprehensive safety. Single speed or double speed is optional, available as fixed type or trolley travelling type. Various capacities, customized lifting height and voltage. Widely used for assembly line, mold workshop, warehouse logistics and matched overhead crane lifting.
Features:
| Grade G80 Lifting Chain | Heat-treated alloy steel G80 chain, wear-resistant and stable under load. |
| Multi Safety Protection System | Power-off brake, overload & limit protection to prevent lifting accidents. |
| Single / Double Speed Optional | Single speed for general transport; double speed for precise load positioning. |
| Flexible Installation & Customization | Fixed or trolley mounting optional; capacity, chain length and voltage customizable. |
Tecnical data:
| Capacity Ton | No. fall | Lifting height M | Lifting speed (m/min) | Power (KW) | Dia of Load Chain MM |
| 0.5T | 0.5-01 | 4M 6M 9M 12M | 7.2 | 1.1 | Φ6.3 |
| 1T | 01-01 | 4M 6M 9M 12M | 6.8 | 1.5 | Φ7.1 |
| 1T | 01-02 | 4M 6M 9M 12M | 3.6 | 1.1 | Φ6.3 |
| 2T | 02-01 | 4M 6M 9M 12M | 6.6 | 3.0 | Φ10.0 |
| 2T | 02-02 | 4M 6M 9M 12M | 3.4 | 1.5 | Φ7.1 |
| 3T | 03-01 | 4M 6M 9M 12M | 5.6 | 3.0 | Φ11.2 |
| 3T | 03-02 | 4M 6M 9M 12M | 3.3 | 3.0 | Φ10.0 |
| 3T | 03-03 | 4M 6M 9M 12M | 2.2 | 1.5 | Φ7.1 |
| 5T | 05-02 | 4M 6M 9M 12M | 2.8 | 3.0 | Φ11.2 |
| 7.5T | 7.5-03 | 4M 6M 9M 12M | 1.8 | 3.0 | Φ11.2 |
| 10T | 10-04 | 4M 6M 9M 12M | 2.8 | 3.0×2 | Φ11.2 |
| 15T | 15-06 | 4M 6M 9M 12M | 1.8 | 3.0×2 | Φ11.2 |
| 20T | 20-08 | 4M 6M 9M 12M | 1.4 | 3.0×2 | Φ11.2 |
| 25T | 25-10 | 4M 6M 9M 12M | 1.1 | 3.0×2 | Φ11.2 |
| 32T | 4M 6M 9M 12M | 3.0×2 | Φ11.2 |
Workshop:
FAQ:
1. Are you manufacturer or trading company?
We are manufacturer with our own factories.
2.What’s the warranty for products?
Usually for 1 year for major part, for example, motor, pump. We also offer online service supports.
3.What’s your MOQ?
Negotiate based on the circumstances. EXW term: 1pcs.
4. What’s your payment term?
100% TT under amount 5000USD, 30%TT as down payment, balance before loading when amount more than 5000USD.
5. What about deliver leading time?
About 15 working days
6. Where’s your factory?
Our factory located in Donglv industrial Area, belongs to Baoding city, near Capital Beijing. Convenient transportation. Our nearest port is Tianjin port.
